CO-EYE HouseStation

Name: CO-EYE HouseStation — Home Monitoring RF Receiver
Brand: CO-EYE

RF House Arrest Monitoring Receiver for Curfew Programs

The CO-EYE HouseStation is an advanced unit with integrated cellular and WIFI modules used for monitoring the presence of a transmitter worn by the monitored individual within a multiple floors building. The receiver has remote programming interfaces so that program configuration and curfew schedules can be tailored for each monitored person.

Request a Quote

Fast & Simple Installation

HouseStation deployment involves quick hardware installation and automatic activation which requires minimal support from the monitoring center. Transmitter pairing, range testing and basic configuration options can be performed from the portal interface.

Robust Solution

The internal battery provides a whole day lasting supervision during power outage. Multiple detection mechanisms on the HouseStation receiver and the participant's body-worn transmitter provide electronic and physical evidence of tamper attempts.

Main Features

Long range monitoring

Enhanced external antenna to penetrate four concrete walls for seamless coverage monitoring of CO-EYE RF i-Bracelet in building, especially for multi-floor house.

Multiple data communication options

The HouseStation incorporates cellular and Wi-Fi communication – allowing selection of the preferred communication platform and providing redundancy when the primary channel is unavailable.

Custom programs and schedules

A wide range of configurable options enable programs that can be adjusted to the specific requirements of each monitored subject including customized curfew schedules.

Advanced tracking methods

Leveraging RF signal strength monitoring, the HouseStation accurately determines participant presence within configurable zones of the approved location.

Encrypted communication

Data transfer to the monitoring center supports HTTPS connection, or proprietary protocols using AES encryption for authentication and validation.

Two-way voice communication

Built-in speaker and microphone enable two-way voice communication between the monitoring center and the participant at the monitored location.

Technical Specifications

Parameter	CO-EYE i-Tracker	CO-EYE HouseStation
Size / Weight	855522mm, 105g	22517355mm, 750g
Operating Temperature	-20 to +60 °C	-20 to +60 °C
Bracelet Monitor	RF and BLE i-Bracelet	RF and BLE i-Bracelet
Cellular Network	GSM / GPRS / EDGE / WCDMA, Micro SIM	GSM / GPRS / EDGE / WCDMA, Micro SIM + dual standard SIM
WiFi Network	2.4G WiFi communication	2.4G WiFi communication
Geo-locate Type	GPS / BeiDou / Galileo / GLONASS / LBS / WiFi	GPS / BeiDou / Galileo / GLONASS / LBS / WiFi
GPS Accuracy	< 5m CEP	< 5m CEP
BLE Connected Mode	Optional CO-EYE ONE-AC	Optional CO-EYE ONE-AC
Battery Life (5 min)	2 days	2 days
Battery Capacity	2300mAh	2300mAh
Recharge Time	2.5 hours, NTC enabled	2.5 hours, NTC enabled
Charging	2mm Jack or mobile power bank	USB-C or mobile power bank
On-board Wireless	433M RFID, Bluetooth, WiFi	433M RFID, Bluetooth, WiFi
On-board Sensors	Barometer, accelerometer	Barometer, accelerometer
On-board Storage	4G, 1-year data storage	4G, 1-year data storage
CPU	4-Core ARM Cortex A7	4-Core ARM Cortex A7
Security	HTTPS/SSL, AES128/256, SM4/SM3/SM2	HTTPS/SSL, AES128/256, SM4/SM3/SM2
Battery Safety	UN38.3	UN38.3
Interaction	LED / voice / vibrator	LED / voice / vibrator / buttons
433M Range	20m indoor, 100m outdoor	50m indoor, 200m outdoor
Phone Functions	N/A	Full functions (independent dual-SIM)
Remote Voice Monitoring	Optional	Optional
Floor Monitoring	Supported (internal barometer)	Supported (internal barometer)
Upgrade	Remote OTA from CO-EYE platform	Remote OTA from CO-EYE platform

Frequently Asked Questions

What is a HouseStation used for in electronic monitoring?

A HouseStation is an indoor base unit that detects the presence of a monitored person within a building. It verifies home curfew compliance by communicating with the offender's ankle bracelet or wristband via BLE and 433MHz radio signals, then reports status to the monitoring center over cellular or WiFi.

Can the HouseStation detect which floor someone is on?

Yes, both HouseStation models include an internal barometer for floor-level monitoring. This enables multi-story curfew enforcement where the system can verify not just building presence but approximate vertical location.

Does the HouseStation need an internet connection?

The HouseStation has built-in 3G WCDMA / 2G GSM cellular connectivity, so it works without WiFi or home internet. It also supports WiFi as backup connectivity. Data is transmitted to the monitoring platform over whichever connection is available.

What devices work with the HouseStation?

The HouseStation pairs with CO-EYE i-Bracelet, Wristband, and other BLE/433MHz transmitters. It supports both standard radio (20m indoor range) and extended range (50m indoor) depending on the model.
